Overview

The Workload Wizard is primarily designed for users that

  • Want to specify business intent for their workload and have the wizard take care of everything required to comply with the intent.

  • Do not want to deal with the learning curve associated with Kubernetes

  • Do not want to develop, test and maintain Kubernetes YAML or Helm charts for their workloads

  • Want "correctly formed" Kubernetes YAML to be automatically generated by the wizard.


High Level Steps

The Workload Wizard takes the user through a few logical, intuitive steps resulting in the definition of the workload's configuration.

Step 1: Create Workload

When creating a new workload,

  • Ensure "Rafay" is selected for the Package Type to ensure the workload wizard is used
  • Specify a name for the workload, the namespace where you would like to deploy it
  • Finally, specify whether the workload requires Ingress or not. If Enabled, the workload wizard will prompt for Ingress related configuration as well.

Create Workload


Step 2: Specify Ingress

If ingress was selected for the workload, the wizard will prompt the user to configure ingress details.

Configure Ingress


Step 3: Configure Containers

The wizard then prompts the user to configure one/more containers that will be part of the workload

Configure Containers


Step 4: Upgrade Policies

Once the containers have been configured, the wizard prompts the user to specify how they would like to perform container upgrades on clusters

Upgrade Policy


Step 5: Placement Policy

The wizard will now prompt the user to specify the type of placement policy they would like to use to deploy their workloads.

Placement Policy


Step 6: Publish Workload

This is the final step in the workload wizard. Once the user attempts to publish the workload, the controller performs the following tasks:

  • Validation of the workload's configuration for errors
  • Auto generation of Kubernetes YAML
  • Send deployment instructions to targeted clusters
  • Check for successful deployment of the workload and report

Upgrade Policy
