Upcoming

Important

The following features are scheduled to roll into Rafay's Preview environment early July 2024. Learn more about Previews. Learn about our recent releases.


v2.8-SaaS

Expected date for roll out to Preview Orgs - July 17, 2024

Azure AKS

Cluster Auto-Upgrade

It will be possible to configure auto-upgrades for AKS clusters with the introduction of this capability. Users will be able to choose to set auto-upgrades for:

  • Cluster Kubernetes version
  • Node OS

Supported interfaces will initially include RCTL, Terraform, and GitOps with write back to Git.

Note: Support for UI will be delivered in a subsequent release.


Amazon EKS

Enabling secret encryption on an existing cluster

Currently, secret encryption with a KMS key can only be configured during cluster creation (Day 0) using the 'save and customize' option. Support is now being added to enable secret encryption on existing clusters (Day 2) as well, along with the option to configure it during cluster creation (Day 0) using the cluster form.

Day 0 Configuration

For new clusters, you can find this configuration in the cluster settings. Based on valid cloud credentials, you will see the option to enable secret encryption during Day 0 configuration.

Existing EKS Cluster

Day 2 Configuration

For existing clusters, you can navigate to the cluster view, then go to Configuration where you will find an option to enable Secret Encryption.

Existing EKS Cluster

RCTL Cluster Configuration with Secret Encryption

kind: Cluster
metadata:
  name: cluster-config
  project: defaultproject
spec:
  blueprint: minimal
  blueprintversion: 2.7.0
  cloudprovider: eks-cloud
  cniprovider: aws-cni
  proxyconfig: {}
  type: eks
---
addons:
- name: coredns
  version: v1.10.1-eksbuild.4
- name: vpc-cni
  version: v1.15.1-eksbuild.1
- name: kube-proxy
  version: v1.28.2-eksbuild.2
- name: aws-ebs-csi-driver
  version: latest
apiVersion: rafay.io/v1alpha5
kind: ClusterConfig
managedNodeGroups:
- amiFamily: AmazonLinux2
  desiredCapacity: 2
  iam:
    withAddonPolicies:
      autoScaler: true
  instanceTypes:
  - t3.xlarge
  maxSize: 2
  minSize: 0
  name: ng-b476082a
  version: "1.28"
  volumeSize: 80
  volumeType: gp3
metadata:
  name: cluster-config
  region: us-west-2
  tags:
    email: [email protected]
    env: dev
  version: "1.28"
secretsEncryption:
  keyARN: arn:aws:kms:us-west-2:xxxxxxxxxxxxx:key/xxxxxxxxxxxxxxx
vpc:
  cidr: 192.168.0.0/16
  clusterEndpoints:
    privateAccess: true
    publicAccess: false
  nat:
    gateway: Single

IAM Permissions Required

When enabling secret encryption with a KMS key on EKS clusters, ensure that the IAM roles or users performing these actions have the following permissions assigned:

  • For key listing: kms:ListKeys
  • For secret encryption: kms:DescribeKey, kms:CreateGrant
  • For Encryption on Existing EKS Cluster : eks:AssociateEncryptionConfig

These permissions are necessary for listing KMS keys, managing encryption grants, and associating an encryption configuration to an existing cluster that don't already have encryption enabled.

Irreversible Action: Secrets Encryption

Once enabled, secrets encryption cannot be disabled. This action is irreversible.


GKE Clusters

Network Policy and Dataplane V2 for GKE Clusters

This enhancement will provide users with advanced networking capabilities ensuring improved security and performance for their applications. Dataplane V2 leverages the power of eBPF, providing enhanced observability, scalability, and resilience, enabling seamless traffic management across clusters. Additionally, Network Policy support allows fine-grained control over network traffic, ensuring that only authorized communications occur between services.

GKE Dataplane


Upstream Kubernetes for Bare Metal and VMs

GitOps SystemSync with Write Back to Git

Users will be able to configure the platform to continuously sync cluster specifications for upstream Kubernetes clusters with a Git repository. Changes can be made in a bidirectional manner.

  • If the cluster specification is updated in the Git repository, the platform will update the corresponding upstream Kubernetes cluster to bring it to the desired state
  • If the upstream Kubernetes cluster's state is modified by an authorized user using the UI or CLI, the changes are automatically written back to the configured Git repository
  • To enable GitOps SystemSync for Upstream Kubernetes (MKS) on Bare Metal and VMs, users must create cloud credentials. These credentials are necessary for GitOps Agent to facilitate the GitOps synchronization.

MKS Git Sync

GitOps Agent Update Required

To use GitOps for upstream cluster types, you must update the GitOps agent to version r2.8.0+.

Cloud Credential Support for Upstream Kubernetes Cluster(MKS)

This release introduces support for managing cloud credentials for upstream Kubernetes clusters (MKS) within the platform. These credentials are essential for enabling GitOps SystemSync functionality and have been integrated into the UI, RCTL, and SystemSync interfaces.

Cloud credentials provide the necessary authentication details for the GitOps Agent to interact with the nodes within your upstream Kubernetes cluster. This includes:

  • GitOps Agent : The GitOps Agent interacts directly with nodes to be part of the cluster. This agent requires connectivity to the nodes and eliminates the need for manual intervention, automating the end-to-end flow through GitOps.

  • SSH Details: SSH credentials used by the GitOps Agent to perform actions on the cluster nodes.

Cloud creds

SystemComponentsPlacement Support

SystemComponentsPlacement allows configuring the scheduling of system components on dedicated nodes.This release introduces support for systemComponentsPlacement as part of the new extended configuration schema. This functionality is currently supported in RCTL,V3 API's and Gitops System Sync.

Using systemComponentsPlacement in RCTL

To utilize systemComponentsPlacement in RCTL, you need to pass the --v3 flag when applying your cluster configuration. Here's an example:

./rctl apply -f <cluster configuration> --v3
apiVersion: infra.k8smgmt.io/v3
kind: Cluster
metadata:
  name: demo-mks
  project: defaultproject
spec:
  blueprint:
    name: minimal
    version: latest
  cloudCredentials: demo-mks-creds
  config:
    autoApproveNodes: true
    dedicatedControlPlane: true
    highAvailability: true
    kubernetesVersion: v1.28.9
    location: sanjose-us
    network:
      cni:
        name: Calico
        version: 3.26.1
      podSubnet: 10.244.0.0/16
      serviceSubnet: 10.96.0.0/12
    nodes:
    - arch: amd64
      hostname: demo-mks-scale-w-tb-2
      operatingSystem: Ubuntu20.04
      privateIP: 10.12.105.227
      roles:
      - Worker
    - arch: amd64
      hostname: demo-mks-scale-w-tb-7
      labels:
        app: infra
      operatingSystem: Ubuntu20.04
      privateIP: 10.12.110.50
      roles:
      - Worker
      taints:
      - effect: NoSchedule
        key: app
        value: infra
    - arch: amd64
      hostname: demo-mks-scale-w-tb-3
      operatingSystem: Ubuntu20.04
      privateIP: 10.12.29.164
      roles:
      - Worker
    - arch: amd64
      hostname: demo-mks-scale-w-tb-6
      labels:
        app: infra
      operatingSystem: Ubuntu20.04
      privateIP: 10.12.101.223
      roles:
      - Worker
      taints:
      - effect: NoSchedule
        key: app
        value: infra
    - arch: amd64
      hostname: demo-mks-scale-c-tb-3
      operatingSystem: Ubuntu20.04
      privateIP: 10.12.118.110
      roles:
      - ControlPlane
  systemComponentsPlacement:
    nodeSelector:
      app: infra
    tolerations:
    - effect: NoSchedule
      key: app
      operator: Equal
      value: infra
    - effect: NoSchedule
      key: infra
      operator: Equal
      value: rafay
  type: mks

Kubernetes Certificate Rotation

Support is being added to rotate Kubernetes certificates for upstream Kubernetes clusters via UI and API. This can be done either manually or automatically based on certificate expiry. This capability streamlines the entire certificate rotation process.

Cert Rotation

Note

Please note that Kubernetes certificate rotation feature described above is not supported in Windows-based upstream clusters.


Environment Manager

RCTL support

With the introduction of this capability, it will be possible to execute Environment Manager workflows using the RCTL Command Line interface utility. RCTL CLI can be embedded into the preferred workflow automation (e.g. CI/CD pipeline) to perform operations such as creation of templates, deployment/shutting down environments.

Support for HCP Terraform Provider

Platform teams will be able to seamlessly integrate and leverage existing investments in HCP Terraform with the introduction of this provider option. With this integration, Platform teams can define templates and enable self-service for developers/data scientists within Rafay while the infrastructure provisioning & management of state files can be handled by HCP Terraform.

Note: This provider option is only available to HashiCorp licensed customers.

HCP Terraform

Support for OpenTofu Provider

Support for OpenTofu provider option is being added as part of the resource template configuration. This provides customers the flexibility to choose the provider of choice for infrastructure provisioning and state management.

Note: Support for Terraform provider option is being deprecated with the introduction of this option.
