System Sync

System Sync enables two Ways or bidirectional Sync to maintain the configuration in the system (system database) and Git repository sync. Any configuration changes performed in the Git repository get reflected in the system, and vice-versa is supported. To achieve this bidirectional sync, external and internal triggers are required. External triggers (Pipeline Triggers) notify whenever resources are modified in a Git repository, and internal triggers notify whenever resources are modified in an internal artifact store.

Cluster Resource System Sync flow

The following are sequence diagrams that illustrate actions in the System sync flow for cluster resource.

Cluster Provision Click Ops flow

sequenceDiagram
    autonumber
    participant Admin
    participant Rafay
    participant AWS/Azure
    participant Customer Git Repo
    rect rgb(191, 223, 255)
    note right of Admin: Day-1:Cluster Provisioning
    Admin->>Rafay: Configure Cluster via Web Console
    Rafay->>AWS/Azure: Provision Cluster
    Rafay->>Customer Git Repo: “Auto Generate” Cluster Spec
    Rafay->>Admin: Cluster Provisioned
    end

Update Cluster GitOps flow

sequenceDiagram
    autonumber
    participant Admin
    participant Rafay
    participant AWS/Azure
    participant Customer Git Repo
    rect rgb(191, 223, 255)
    note right of Admin: Day2: Scale and upgrade via gitops
    Admin->>Customer Git Repo: Git PR to update cluster spec
    Customer Git Repo->> Rafay: Webhook notification
    Rafay->>AWS/Azure: Bring cluster to desired state
    Rafay->>Admin: Cluster Updated
    end

Update Cluster Click Ops flow

sequenceDiagram
    autonumber
    participant Admin
    participant Rafay
    participant AWS/Azure
    participant Customer Git Repo
    rect rgb(191, 223, 255)
    note right of Admin: Day2: Scale and upgrade via ClickOps
    Admin->>Rafay:Update Cluster via WebConsole
    Rafay->> AWS/Azure: Update Cluster
    Rafay->>Customer Git Repo: Auto Update Cluster spec
    Rafay->>Admin: Cluster Updated
    end

Pre-requisites

System Sync Stage requires the below setup to complete the sync successfully

Github Repository

  • User should create a valid Git repository
  • Update the created repository in the Repositories page with an appropriate name

GitOps Agents

  • Create GitOps Agents and associate with the K8s Cluster for secured connectivity to the repositories
  • Git Repo used for System-Sync must be associated with the GitOps agent. This helps to access the repositories available in the private network

System Sync Operation

This stage is responsible for resource config sync between Git Repository and the system

  • Provide a friendly name for the stage
  • Select System Sync

Git To System Sync

  • To sync the resource specification from Git Repository to System, select Git To System Sync checkbox
  • Select the Repository from where the resource details are to be cloned
  • Provide the Tag/Branch of the repository
  • Provide the appropriate Folder path of the repository

Git to System

When a commit occurs in the Git repository and triggers a Git-to-system sync, users will receive information about the paths of the resources that have been modified or updated by scanning the entire repository. During the initial Git-to-system sync, the system is updated with all lineage information. However, for subsequent modifications to resources in the repository, only the specific resource path will be displayed in the pipeline.

A resource sourced from Git can only be deleted if it existed in the repository during any synchronization from Git to the system, and these changes will be visible in the pipeline as shown below

Git to System

If attempting to delete a resource not created or updated in Git, the following error message will appear

Git to System

System to Git Sync

  • To sync the resource specification (updated through Controller) from system to Git Repository to System, select System To Git Sync checkbox
  • Select the Repository to which the resource details must be synced
  • Provide the Tag/Branch of the repository
  • Provide the appropriate Folder path of the repository

System to Git

  • Select Use Source As Destination checkbox to use the same source destination (or) uncheck this option to provide a different (system or repo) destination

Include / Exclude Resources

Include Resources allows the users to add all the resources or add only the required resources anytime. Click Add Resource to include one or more resources. This operation sync only the selected resource(s) in Git Repository and System. Below are the supported resources

  • Add-On
  • Blueprint
  • Catalog
  • Cluster
  • Cluster Network Policy
  • Cluster Network Policy Rule
  • Cluster Overrides
  • Cost Profile
  • Fleet Plan
  • Gitops Agent
  • Infrastructure Provisioner
  • Namespace
  • Namespace Network Policy
  • Namespace Network Policy Rule
  • Network Policy Installation Profile
  • OPA Constraint
  • OPA Constraint Template
  • OPA Installation Profile
  • OPA Policy
  • Pipeline
  • Repository
  • Secret Provider Class
  • Secret Sealer
  • Secret Store
  • Workload
  • Workload Template

Important

Add-On from Catalog and Workload from Catalog system sync can be performed using the respective YAML spec available in the Git Repo. The parameter catalog: default-bitnami in the workload and add-on YAML spec represents the catalog functionality

By default, All Resources are selected from the drop-down

Exclude Resource allow the users to remove the resource(s) anytime. Click Add Resource to exclude one or more resources

Include/Exclude Resources

During System to Git Sync, regardless of whether any resource configuration files are available to sync, a new project folder with a git-ignore file named .gitkeep will be created in the selected git repo when triggering a pipeline. Users can add or remove the resources at any time. A project folder cannot be empty in the git repo, thus deleting the .gitkeep file where the project folder doesn't have any other resource configuration files, results in deleting the project folder itself. When you delete that .gitkeep file, the same file will get created on the next pipeline run.

Include/Exclude Resources

Pre-Conditions (Optional)

Stages can be configured to execute ONLY if the expression matches the specified pre-conditions

Stage Variables (Optional)

All the variables available for a given stage are fetched as a sorted list according to their scope (Organization -> Project -> Pipeline -> Trigger -> Stage). These variables are evaluated with the environment. The environment is then updated with the variable according to their scope

Click Save to add the system sync stage to the pipeline or Cancel to abort the process. Click Save and Go To Triggers to complete the sync process and trigger the changes

Add to Triggers

Refer Triggers for more information

Success System Sync

The System Sync job begins automatically in the pipeline. The initial status is In Progress, later changes to Success. Use the Run button to trigger the pipeline for the changes performed manually in the system

Add to Triggers

Users can view the recently triggered changes on the Triggers page. Also, this creates a pipeline in Git Repo with all the selected resources in the specified project. Below is an example of defaultproject and the list of included resources

Resources in Git Repo

Below is an example of the add-ons resource in Git Repository where the users can view or update the resource specs based on the selected direction during system sync stage creation

Git Directory Structure for resource(s) sync: Repo_name/folder_name (provided by the customer)/projects/project_name/resource_name (example: cluster, addons, blueprint)

Git Repo Specs

Important

When a resource contains a secret value/key, the system sync fails for that specific resource, but continues with the other resources. Currently, Infrastructure Provisioners is the only resource that can contain a secure text. Refer Secret Sealer on how to configure secrets for Infra Provisioners.

Refer Infrastructure Provisioners for more details on Infrastructure Provisioners configurations

Cluster Resource

The resource Cluster system sync is applicable for AKS, EKS and GKE clusters.

Examples

Below is an example of the AKS cluster resource yaml for cluster system sync process

apiVersion: infra.k8smgmt.io/v3
kind: Cluster
metadata:
  name: testazure
  project: default
spec:
  blueprintConfig:
    name: minimal
  cloudCredentials: azure
  config:
    kind: aksClusterConfig
    metadata:
      name: testazure
    spec:
      managedCluster:
        apiVersion: "2022-07-01"
        identity:
          type: SystemAssigned
        location: centralindia
        properties:
          apiServerAccessProfile:
            enablePrivateCluster: true
          dnsPrefix: testazure-dns
          kubernetesVersion: 1.24.9
          networkProfile:
            dnsServiceIP: 10.0.0.10
            dockerBridgeCidr: 172.17.0.1/16
            loadBalancerSku: standard
            networkPlugin: azure
            serviceCidr: 10.0.0.0/16
        sku:
          name: Basic
          tier: Free
        tags:
          email: [email protected]
          env: qa
        type: Microsoft.ContainerService/managedClusters
      nodePools:
      - apiVersion: "2022-07-01"
        location: centralindia
        name: primary
        properties:
          count: 1
          enableAutoScaling: true
          maxCount: 1
          maxPods: 110
          minCount: 1
          mode: System
          orchestratorVersion: 1.24.9
          osType: Linux
          type: VirtualMachineScaleSets
          vmSize: Standard_B2ms
        type: Microsoft.ContainerService/managedClusters/agentPools
      - apiVersion: "2022-07-01"
        location: centralindia
        name: np2
        properties:
          count: 1
          enableAutoScaling: true
          maxCount: 1
          maxPods: 110
          minCount: 1
          mode: User
          orchestratorVersion: 1.24.9
          osType: Linux
          type: VirtualMachineScaleSets
          vmSize: Standard_B2ms
        type: Microsoft.ContainerService/managedClusters/agentPools
      resourceGroupName: demo-rg
  proxyConfig: {}
  type: aks

Below is an example of the EKS cluster resource yaml for cluster system sync process

apiVersion: infra.k8smgmt.io/v3
kind: Cluster
metadata:
  name: demo-cluster
  project: default
spec:
  blueprintConfig:
    name: demo-bp
    version: v1
  cloudCredentials: demo_aws
  config:
    managedNodeGroups:
    - amiFamily: AmazonLinux2
      desiredCapacity: 1
      iam:
        withAddonPolicies:
          autoScaler: true
      instanceType: t3.xlarge
      maxSize: 2
      minSize: 0
      name: managed-ng-1
      version: "1.22"
      volumeSize: 80
      volumeType: gp3
    metadata:
      name: demo-cluster
      region: us-west-2
      version: "1.22"
    network:
      cni:
        name: aws-cni
        params:
          customCniCrdSpec:
            us-west-2a:
            - securityGroups:
              - sg-09706d2348936a2b1
              subnet: subnet-0f854d90d85509df9
            us-west-2b:
            - securityGroups:
              - sg-09706d2348936a2b1
              subnet: subnet-0301d84c8b9f82fd1
    vpc:
      clusterEndpoints:
        privateAccess: false
        publicAccess: true
      nat:
        gateway: Single
      subnets:
        private:
          subnet-06e99eb57fcf4f117:
            id: subnet-06e99eb57fcf4f117
          subnet-0509b963a387f7fc7:
            id: subnet-0509b963a387f7fc7
        public:
          subnet-056b49f76124e37ec:
            id: subnet-056b49f76124e37ec
          subnet-0e8e6d17f6cb05b29:
            id: subnet-0e8e6d17f6cb05b29
  proxyConfig: {}
  type: aws-eks

Below is an example of the GKE cluster resource yaml for cluster system sync process

{
    "Cluster": {
